Description
Specifications | |
---|---|
Operating System | Android 7.0 |
Processor | Samsung Exynos8895V octa-core Processor (2.3GHz Quad-core Mongoose + 1.7GHz Quad-core A53) |
Memory | 4GB RAM, 256GB On-board Memory |
Display | 12.7 inch TFT-LCD with 2732 x 2048 resolution capacitive touchscreen |
Connectivity |
WiFix2 (802.11 a/b/g/n/ac 2×2 MIMO), BT v.2.1 + EDR, GPS USB 2.0 (Two USB HOST Type A, one USB mini device), HDMI 2.0, SD Card (Support up to 256GB) |
Camera |
Rear: 16 Megapixel, Autofocus with Flashlight Front: 5 Megapixel |
Sensors | Gravity Accelerometer, Ambient Light Sensor (ALS) |
Audio Input/Output | Microphone, Dual Speakers, 3-Band 3.5 mm stereo/standard headset jack |
Power and Battery |
18000mAh 3.8 V lithium-polymer battery Charging via 12 V AC/DC power supply with the temperature between 0°C and 45°C |
Input Voltage | 12V/3A Adapter |
Operating Temp. | 0 to 50°C (32 to 122°F) |
Storage Temp. | -20 to 60°C (-4 to 140°F) |
Dimensions (W x H x D) | 366.5 mm (14.43″) x 280.9 mm (11.06″) x 34 mm (1.34″) |
Weight | 2.18kg (4.81 lb.) |
Protocols |
DoIP, PLC J2497, ISO-15765, SAE-J1939, ISO-14229 UDS, SAE-J2411 Single Wire Can (GMLAN), ISO-11898-2, ISO-11898-3, SAE-J2819 (TP20), TP16, ISO-9141, ISO-14230, SAE-J2610 (Chrysler SCI), UART Echo Byte, SAE-J2809 (Honda Diag-H), SAE-J2740 (GM ALDL), SAE-J1567 (CCD BUS), Ford UBP, Nissan DDL UART with Clock, BMW DS2, BMW DS1, SAE J2819 (VAG KW81), KW82, SAE J1708, SAE-J1850 PWM (Ford SCP), SAE-J1850 VPW (GM Class2) |
